28m Putzmeister Concrete Placing Boom Stationary
Our Product Introduction
for more products please visit us on sunnyconcretebatchingplant.com
Basic Information
Place of Origin:
Hunan
Brand Name:
Sunny
Model Number:
HG28
Minimum Order Quantity:
1 set
Price:
USD6000-10000 PER SET
Delivery Time:
20-35DAYS
Payment Terms:
L/C, T/T, Western Union, MoneyGram
Supply Ability:
50 SET PER MONTH
28m Putzmeister Concrete Placing Boom Stationary
Product Specification
Condition:
New
Warranty:
1 Year
After-sales Service Provided:
Engineers Available To Service Machinery Overseas
Application:
Construction Engineering
Keyword:
Concrete Pump
Highlight:

putzmeister concrete placing boom

,

placing boom for concrete pump

,

concrete placing boom putzmeister

28m Putzmeister Concrete Placing Boom Stationary
Our Product Introduction
for more products please visit us on sunnyconcretebatchingplant.com
Product Description

28m concrete placing boom stationary putzmeister placing boom boom placer pump

The benefits of using a concrete placing pump are numerous. Firstly, it significantly improves productivity by delivering large volumes of concrete quickly and continuously. This reduces the reliance on manual labor and speeds up construction timelines. Secondly, a concrete placing pump enables precise placement of concrete, even in challenging or inaccessible areas. The operator can control the pumping speed, pressure, and flow rate, ensuring accurate positioning and minimizing material waste.

Moreover, concrete placing pumps offer versatility in handling different types of concrete mixes, including low slump, high slump, and lightweight concrete. They can be used for a wide range of construction applications, such as foundations, slabs, walls, columns, and even high-rise structures. The pumps are capable of pumping concrete both horizontally and vertically, allowing for flexibility in placement options and accommodating projects with varying elevation levels.

Item
HG28
HG32
Max. Placing
Radius (M)
27.5
32
Big Arm Length (M)
12.6
14.5
Big Arm Elevation (°)
0-65
0-65
Medium Arm Length (M)
8.8
9.2
Medium Arm
Elevation (°)
0-180
0-180
Small Arm Length (M)
6.1
8
Small Arm Elevation (°)
0-180
0-180
Hose Length (M)
3
3
Concrete Delivery
Pipe (Mm)
Ø125×6
Ø125×6
Tail Rotary Radius (M)
3.9
-
Total Power (Kw)
5.5
15
System Pressure (Mpa)
24
24
Rotary Speed (R/Min)
0.3-0.8
0.3-0.8
Rotary Range (°)
0-360
0-360
Lifting Speed (M/Min)
0.65
0.65
Lifting Height(M/Time)
≤3.6
≤3.6
Overall Height (M)
12.6
22.9
Bare Machine Weight (Kg)
10720
16700
Balance Weight(Kg)
4×2000
-
Control Mode
Panel/Wireless Remote Control
